Specs
Engine
| Enigine Fuel | Diesel |
|---|
| Maximum Governed RPM | 2,550 rpm |
|---|
| Horsepower | 24.8 hp |
|---|
| Turbo Charged Engine | |
|---|
Performance
| Operating Weight | 6,489 lb |
|---|
| Weight Class | 2.9 t |
|---|
| Travel Speed High | 3.2 mph |
|---|
| Travel Speed Low | 1.8 mph |
|---|
| Arm Digging Force | 3,547 lbf |
|---|
| Bucket Digging Force | 5,652 lbf |
|---|
| Rated Lift Capacity | 2359 lb |
|---|
| Lift Radius | 118 in |
|---|
| Boom Swing Left | 70° |
|---|
| Boom Swing Right | 55° |
|---|
| Maximum Dig Depth | 9.5 ft |
|---|
| Max Dump Height | 10.4 ft |
|---|
| Maximum Reach at Ground Level | 16 ft |
|---|
Capacities
| Fuel Tank | 9.1 gal |
|---|
Hydraulic System
| Auxiliary Std Flow | 14.2 gal/min |
|---|
| Auxiliary Pressure | 2,611 psi |
|---|
Dimension
| Length | 170.4 in |
|---|
| Overall Length in Travel Position | 170.4 in |
|---|
| Width | 61 in |
|---|
| Height | 96 in |
|---|
| Height With Operator Cab | 96 in |
|---|
Features
| Air Conditioning | N/A |
|---|
| Cab Enclosure | Optional |
|---|
| Cab Heater | N/A |
|---|
| Heater Air Conditioning | Optional |
|---|
| Radio | Optional |
|---|
| Tail Swing Type | Minimal |
|---|
| Engine Shutdown | Standard |
|---|
| Auxiliary Hydraulics | Standard |
|---|
| Secondary Auxiliary Hydraulics | N/A |
|---|
| Quick Tach System | Standard |
|---|
| Rubber Track | Standard |
|---|
| Angle Blade | N/A |
|---|
